Description
The Trina Solar Vertex S+ 445W NE09RH module brings
best-in-class performance to residential and small commercial rooftops. This
N-type i-TOPCon backsheet module delivers high power density in a compact form
factor, making it easier to install and perfect for projects with limited roof
space. Engineered with advanced design features for superior hail and wind
resistance, the Vertex S+ ensures dependable power production even in
challenging weather conditions.
Enjoy the benefits of Trina Protect, a combined 25-year product
and 25-year power warranty that safeguards your investment over the long term.
With a first-year degradation of only 1% and an annual degradation of 0.4%
thereafter, these modules yield a consistently high energy output. Whether you
aim to maximize performance in residential settings or enhance your commercial
rooftop’s aesthetics, the all-black Vertex S+ is a visually appealing,
high-performing, and reliable choice.
Key Features & Benefits
- Ultra High Power & Efficiency: Up to 445W output and up to 22.3% module efficiency.
- N-type i-TOPCon Technology: Low-temperature coefficient and minimal LID/LeTID effects, ensuring high performance over the module’s lifespan.
- All-Black Aesthetics: Designed for sleek residential rooftops, delivering premium curb appeal.
- Hail & Wind Resistant: Engineered to withstand harsh weather, including hailstorms, providing extra security in extreme environments.
- Reduced Degradation: 1% first-year degradation, 0.4% annually thereafter, ensuring long-term reliability.
- Robust Warranty: 25-year product workmanship and 25-year power guarantee for peace of mind.
- Ideal for Residential & C&I Roofs: Smaller footprint, easier handling, and compatibility with mainstream inverters and mounting systems.
- Assembled in the USA from Imported Components: Supporting local job creation and meeting certain domestic content criteria (where applicable).
Technical Specifications
| General Information | |
|---|---|
| Model | US/Vertex S+ 445W NE09RH (TSM-NE09RH.05) |
| Cell Type | N-type i-TOPCon Monocrystalline (96 cells) |
| Module Power Range | 420–445W |
| Module Efficiency | Up to 22.3% |
| Power Tolerance | 0 ~ +3% |
| Product Warranty | 25 Years (Workmanship) |
| Power Warranty | 25 Years (25-year Power Guarantee) |
| Electrical (STC) | |
| Maximum Power (Pmax) | Up to 445W |
| Open-Circuit Voltage (VOC) | Up to ~35.1V |
| Short-Circuit Current (ISC) | Up to ~16.07A |
| Maximum System Voltage | 1500V DC (IEC/UL) |
| Series Fuse Rating | 30A |
| Mechanical & Operating | |
| Dimensions (L × W × H) | 1762 × 1134 × 35 mm (69.37 × 44.65 × 1.38 inches) |
| Weight | 21.5 kg (47.4 lbs) |
| Glass & Backsheet | 3.2 mm Tempered Glass (AR Coating) & White-Black Opaque Backsheet |
| Frame | 35 mm Anodized Aluminum Alloy (Black) |
| Connector | MC4 EVO2 (Region-specific variants may apply) |
| Cable Length | 1100 mm / 1100 mm (Landscape) |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Fire Type | Type 1 or Type 2 (Region-dependent) |
| Wind & Snow Loads | Up to 5400 Pa (Front) / 5400 Pa (Rear) |
STC = Irradiance 1000 W/m², Cell Temperature 25°C, AM1.5.
Measurements subject to ±3% tolerance.
Full specifications are preliminary and may change without notice.
Why Choose Vertex S+ 445W NE09RH?
- Enhanced Hail Protection: Specially engineered to resist hail damage, mitigating the risk of costly repairs.
- Durable & Reliable: Rigorously tested to withstand wind, snow, salt mist, and sand, ensuring stable performance in diverse environments.
- Optimized for US Residential: Assembled in the USA from imported components for quicker deployments and potential domestic content benefits.
- Aesthetic Appeal: The black frame and black backsheet integrate seamlessly with residential roofs for a refined, modern look.
Warranty & Support
- 25-Year Product Warranty: Covers materials and workmanship.
- 25-Year Power Warranty: Guarantees minimal degradation and stable energy output.
- Local Support Team: Trina Solar’s US-based experts offer timely assistance and guidance for your project’s success.
Packaging & Shipping
- Modules per Box: 31 pieces
- Modules per 53′ Container: 868 pieces
- Strategic packaging design to reduce handling costs and breakage risks.
Installation & Safety
Always follow the installation manuals and safety guidelines provided
by Trina Solar. Ensure compliance with all local regulations, building codes,
and permit requirements.
About Trina Solar
Trina Solar is a leading global provider of PV solutions, recognized for
outstanding innovation, product reliability, and service excellence. By choosing
Trina Solar, you are investing in high-quality modules backed by a proven
commitment to sustainability and performance.
Download the Datasheet
For more technical details and certifications, please refer to the
official product datasheet (PDF)
